HIKMICRO Mini Smartphone Module

(No reviews yet) Write a Review
SKU:
308200142
  • HIKMICRO Mini1 Smartphone Module
  • HIKMICRO Mini1 - Photo 2
  • HIKMICRO Mini1 - Photo 3
  • HIKMICRO Warranty
$395.00

Description

HIKMICRO Mini1 - Banner

The Smartphone Module is designed to inspect electrical equipment, troubleshooting HVAC problems. Equipped with functional thermal App for smartphone, the Smartphone Module enables you to get the thermal imaging on your phone.



HIKMICRO Mini1 - High Image Quality

HIKMICRO Mini1 - Fast Image Frequency

HIKMICRO Mini1 - Mini Design

HIKMICRO Mini1 - Accurate Temperature Measurement

HIKMICRO Mini1 - Smartphone App

HIKMICRO Mini1 - Quick Temperature Measurement

HIKMICRO Mini1 - High Temperature Alarm

HIKMICRO Mini1 - Different Colour Palettes

View AllClose

Videos

View AllClose

Specifications

Resolution (pixels):
160 × 120
Accuracy:
Max (±2°C, ±2%), applicable 60 sec after start-up when the ambient temperature 15°C to 35°C and object temperature above 0°C
Temperature Measuring Range (°C):
-20 to 350
Smartphone:
Android (USB Type-C Interface)
Video Format:
MP4
Image Format:
JPEG
Field of View:
50° × 38° (H × V)
Image Frequency:
25 Hz
Protection Level:
IP40
Measurement Presets:
Hot Spot, Cold Spot, Center Spot, 1 Point Preset, 1 Area Preset, Off
Weight (g):
26
Length (mm):
54.1
Width (mm):
15
Height (mm):
27.5
Product Type:
Smartphone Adaptor
Connectivity:
USB
Connectivity:
USB-C
Focus:
Fixed
